【大智慧】《云制MACD顶底背离》【副图】

{云制MACD顶底背离}

VAR1:=BARSLAST(REF(CROSS(EMA(C,13) - EMA(C,34),EMA(EMA(C,13) - EMA(C,34) ,12)),1));

VAR2:=BARSLAST(REF(CROSS(EMA(EMA(C,13) - EMA(C,34) ,12),EMA(C,13) - EMA(C,34) ),1));

VAR3:=LLV(L,VAR2 + 3);

VAR4:=HHV(H,VAR1 +3);

DIFF:EMA(C,13) - EMA(C,34) ;

DEA:EMA(EMA(C,13) - EMA(C,34),12) ;

MACD:1.5 * (EMA(C,13) - EMA(C,34) - EMA(EMA(C,13) - EMA(C,34) ,12) ),NODRAW ;

STICKLINE((MACD > 0),0,MACD,2.5,0),COLOR0000CC;

STICKLINE((MACD > 0),0,MACD*0.9,2.5 ,0),COLOR0000EE;

STICKLINE((MACD > 0),0,MACD*0.8,2.5 ,0),COLOR0011FF;

STICKLINE((MACD > 0),0,MACD*0.7,2.5 ,0),COLOR0033FF;

STICKLINE((MACD > 0),0,MACD*0.6,2.5 ,0),COLOR0055FF;

STICKLINE((MACD > 0),0,MACD*0.5,2.5 ,0),COLOR0077FF;

STICKLINE((MACD > 0),0,MACD*0.4,2.5 ,0),COLOR0099FF;

STICKLINE((MACD > 0),0,MACD*0.3,2.5 ,0),COLOR00BBFF;

STICKLINE((MACD > 0),0,MACD*0.2,2.5 ,0),COLOR00DDFF;

STICKLINE((MACD > 0),0,MACD*0.1,2.5 ,0),COLOR00FFFF;

STICKLINE((MACD < 0),0,MACD,2.5 ,0),COLORCC0033;

STICKLINE((MACD < 0),0,MACD*0.9,2.5 ,0),COLOREE0033;

STICKLINE((MACD < 0),0,MACD*0.8,2.5 ,0),COLORFF1133;

STICKLINE((MACD < 0),0,MACD*0.7,2.5 ,0),COLORFF3333;

STICKLINE((MACD < 0),0,MACD*0.6,2.5 ,0),COLORFF5533;

STICKLINE((MACD < 0),0,MACD*0.5,2.5 ,0),COLORFF7733;

STICKLINE((MACD < 0),0,MACD*0.4,2.5 ,0),COLORFF9933;

STICKLINE((MACD < 0),0,MACD*0.3,2.5 ,0),COLORFFBB33;

STICKLINE((MACD < 0),0,MACD*0.2,2.5 ,0),COLORFFDD33;

STICKLINE((MACD < 0),0,MACD*0.1,2.5 ,0),COLORFFFF33;

IF(EMA(C,13) - EMA(C,34) >= EMA(EMA(C,13) - EMA(C,34) ,12),EMA(C,13) - EMA(C,34) ,DRAWNULL),COLORRED;

IF((EMA(C,13) - EMA(C,34) - EMA(EMA(C,13) - EMA(C,34) ,12) ) * 1000/EMA(C,15) > 0 AND (EMA(C,13) - EMA(C,34) - EMA(EMA(C,13) - EMA(C,34) ,12) ) * 1000/EMA(C,15) < 1.85,EMA(C,13) - EMA(C,34),DRAWNULL),COLORGREEN;

IF(EMA(C,13) - EMA(C,34) < EMA(EMA(C,13) - EMA(C,34) ,12) OR EMA(C,13) - EMA(C,34) > EMA(EMA(C,13) - EMA(C,34) ,12) AND REF(EMA(C,13) - EMA(C,34) ,1) < REF(EMA(EMA(C,13) - EMA(C,34) ,12) ,1),EMA(C,13) - EMA(C,34) ,DRAWNULL),COLORFF0000;

MACD底背离:REF(VAR3,VAR1 + 1) > VAR3 AND REF(EMA(C,13) - EMA(C,34) ,VAR1 + 1) < EMA(C,13) - EMA(C,34) AND CROSS(EMA(C,13) - EMA(C,34),EMA(EMA(C,13) - EMA(C,34) ,12) ),NODRAW,COLORRED;

DRAWTEXT(REF(VAR3,VAR1 + 1) > VAR3 AND REF(EMA(C,13) - EMA(C,34) ,VAR1 + 1) < EMA(C,13) - EMA(C,34) AND CROSS(EMA(C,13) - EMA(C,34) ,EMA(EMA(C,13) - EMA(C,34) ,12) ),EMA(EMA(C,13) - EMA(C,34) ,12)-0.04,'底'),COLOR00FFFF;

DRAWTEXT(REF(VAR3,VAR1 + 1) > VAR3 AND REF(EMA(C,13) - EMA(C,34) ,VAR1 + 1) < EMA(C,13) - EMA(C,34) AND CROSS(EMA(C,13) - EMA(C,34) ,EMA(EMA(C,13) - EMA(C,34) ,12) ),EMA(EMA(C,13) - EMA(C,34) ,12)-0.08,'背'),COLOR00FFFF;

MACD顶背离:REF(VAR4,VAR2 + 1) < VAR4 AND REF(EMA(C,13) - EMA(C,34) ,VAR2 + 1) > EMA(C,13) - EMA(C,34) AND CROSS(EMA(EMA(C,13) - EMA(C,34) ,12) ,EMA(C,13) - EMA(C,34) ),NODRAW,COLORGREEN;

DRAWTEXT(REF(VAR4,VAR2 + 1) < VAR4 AND REF(EMA(C,13) - EMA(C,34) ,VAR2 + 1) > EMA(C,13) - EMA(C,34) AND CROSS(EMA(EMA(C,13) - EMA(C,34) ,12) ,EMA(C,13) - EMA(C,34) ),EMA(EMA(C,13) - EMA(C,34) ,12)+0.08,'顶'),COLORFFFF00;

DRAWTEXT(REF(VAR4,VAR2 + 1) < VAR4 AND REF(EMA(C,13) - EMA(C,34) ,VAR2 + 1) > EMA(C,13) - EMA(C,34) AND CROSS(EMA(EMA(C,13) - EMA(C,34) ,12) ,EMA(C,13) - EMA(C,34) ),EMA(EMA(C,13) - EMA(C,34) ,12)+0.04,'背'),COLORFFFF00;

DRAWICON(CROSS(EMA(C,13) - EMA(C,34) >= EMA(EMA(C,13) - EMA(C,34) ,12),0.5),EMA(EMA(C,13) - EMA(C,34) ,12) ,5);

DRAWICON(CROSS(EMA(EMA(C,13) - EMA(C,34) ,12) >=EMA(C,13) - EMA(C,34) ,0.5),EMA(EMA(C,13) - EMA(C,34) ,12) ,6);
